Features

1. Processor & Graphics

   Equipped with Intel® Celeron™ N95/ N100 N series Processor. Integrated Intel UHD Graphics, max dynamic frequency 1.0GHz.
2. Memory & Storage

• Dual DDR5 SO-DIMM slots, maximum 96GB RAM
• 1×M.2 NVMe slot pre-installed with 512GB storage; 1x PCIEx4 for extension

3. Dual 2.5G Ethernet

   Dual Intel I226V 2.5G RJ45 ports. Supports Wake on LAN, timed boot, PXE diskless boot.
4. Rich Serial & I/O Interfaces

• 6×DB9 COM ports; COM1/COM2 configurable as RS232/422/485 via BIOS
• 6×USB3.0 + 4×USB2.0 Pin
• 1×HDMI1.4 (4096×2160@24Hz), 1x VGA Pin, 1x LVDS/ EDP Pin
• MIC input, speaker output, power button, DC 12V power jack
• 8 GPIO pins (4 input + 4 output)

5. Dual Mini PCIE Expansion Slots

   One slot for Wi-Fi/Bluetooth module; another for 3G/4G cellular modules.
6. Cooling & Structure

   Fanless aluminum enclosure, low noise and low power consumption.

   Size: 182mm×106mm×64mm, weight 1.8kg. Supports desktop and wall mounting.
7. Wide Operating Environment

   Operating temperature: -20℃ ~ +65℃; storage temperature: -30℃ ~ +70℃.

   Humidity: 5%–95% non-condensing relative humidity.
8. Power Supply & System

   DC 12V/6A power input. Preloaded Windows 10 IoT ENT LTSC.

   Supports timed automatic startup.
