INYUDA HM86-OPS Features

1. Processor & Chipset

   Intel HM86 chipset, PGA946 socket, supports 4th Gen Haswell mobile CPU (i3/i5/i7). Integrated Intel HD Graphics.
2. Memory

   Single DDR3 SO-DIMM slot, max 8GB 1600MHz.
3. Display Output

   External HDMI + VGA; standard 80-pin OPS HDMI interface, supports 4K@60Hz, asynchronous dual display.
4. Storage Interfaces

   1×mSATA slot + 1×2.5-inch SATA bay for SSD/HDD.
5. Expansion Slot

   M.2 2230 slot for Wi-Fi & Bluetooth modules.
6. Network

   Onboard Realtek RTL8111F gigabit Ethernet, supports Wake on LAN and PXE boot.
7. I/O Ports

   4×USB3.0 + 2×USB2.0, 3.5mm MIC & Line-out combo audio, power button, one-key restore. Reserved RS232 serial pin header.
8. Standard OPS Structure

   80-pin JATEX pluggable OPS port, all video/audio/power/control signals integrated for interactive panels.
9. Power Input

   DC 12V wide voltage input, compatible with mainstream all-in-one display power adapters.
10. Cooling & BIOS

    Built-in CPU fan header, AMI BIOS, supports auto power-on and watchdog function.
11. Environment Adaptation

    Operating temperature 0℃~60℃, storage -20℃~75℃, 0%–95% non-condensing humidity.
